Instruction
1. Make a group of design project with maximum 4 number of student.
2. The Group must be define A set of Architecture Drawing for Double Storey Building.
The Drawing must in A1 or AO size only with details :-
Scale 1:100
a) Ground Floor Plan
b) First Floor Plan
c) Roof Plan
d) Front Elevation
e) Rear Elevation
f) Left Side Elevation
g) Right Side Elevation
h) X-X Section Elevation
i) Y-Y Section Elevation
3. By using Architecture Drawing, Student will be able to assembles and coordinates elements of structural to organize and display in Structural Layout Plan drawing which shown suitable size of proposed :-
a) Beam (Ground Beam Layout Plan, First Floor Beam Layout Plan & Roof
Beam Layout Plan) for double storey building. (6 marks)
b) Show Floor Slab in One Way or Two Way Direction each Panel &
Proposed of thickness of Slab for suspended slab. (2 marks)
c) Column & Pad Footing positioning. (4 marks)
CLO 2&3
C5, A4
DK 2,4,5,6&7
DP 1,3&5
4. By using Architecture Drawing and Structural Layout Plan drawing, Student will be able to manipulate and make the assumption of loading for all level of plan. (2 marks)
5. By using Structural Layout Plan drawing, every Student in group will be able creating in designing of element (including detailing drawing) :-
a) A simply supported of beam (5 marks)
b) A panel of slab (5 marks)
c) one of column element (including detailing drawing) from Footing to
Roof level. (10 marks)
d) A Single pad Footing (5 marks)
In different location and situation.
CLO 2&3
C5,A4
DK 2,4,5,6&7
DP 1,3&5
6. All the instruction no.2 to 6 must submit in Group Report (Filing or Binding in one of Design Report). (1 marks)
CLO 3
A4
DK 5&7
